Lifecycle
- Obsolete Date 31-10-2026
Specifications
- Host interface 8-ports 10/25GbE iSCSI, 4 ports per controller
- Storage controller 2 per array, 4-ports each (8-ports total)
- Host connectivity 16 Gb Fibre Channel, 10/25 GbE iSCSI, 10GBase-T iSCSI, or 12 Gb SAS; depending on model
- Weight 11 lb
- Systems Insight Manager support No
- Drive description Bundled with 12x 960 GB SAS RI SFF SSD drives; Add up to 12x additional SFF HDD and/or SSD drives per array model
- Form factor 2U rack mount
- SAN backup support Yes
- Warranty Three-year limited warranty, parts exchange next business day delivery. Disk enclosures, hard drives and options for the HPE MSA 2060 carry their own warranty.
- Clustering support Yes
- Weight 5 kg
- Storage expansion options 24 drive bay 2060 SFF drive enclosure and/or 12 drive bay 2060 LFF drive enclosure (add up to 9)
- Capacity Up to 1,762.56 TB with all SFF expansion / 2,263.68 TB with combined SFF & LFF expansion (with maximum expansion)
- Storage mirroring support No
- Energy efficiency Energy Star Compliant
- Product dimensions (imperial) 3.5 x 17.5 x 20.0 in
- Compatible operating systems Windows Server 2022 Windows Server 2019 Windows Server 2016 VMWare vSphere 6.7 Red Hat Linux 8 SuSE SLES 15
- Product dimensions (metric) 8.9 x 44.5 x 50.8 cm
Quickspecs
Overview
Is your company looking for easy-to-use, affordable, and high-performance shared storage? The HPE MSA 2060 Storage is a flash-ready hybrid storage system designed to deliver hands-free, affordable application acceleration for small and remote office deployments. Don’t let the low cost fool you. It gives you the combination of simplicity, flexibility, and advanced features you may not expect in an entry-priced array. Start small and scale as needed with any combination of solid state drives (SSDs), high-performance Enterprise SAS HDDs, or lower-cost Midline SAS HDDs. With the ability to deliver up to 395,000 IOPS, the new HPE MSA 2060 is up to 80% faster than its prior generation with ample horsepower for even the most demanding workloads. [1]
What’s new
- Customer configurable HPE MSA 2060 storage array models and storage media options available through the HPE Smart Choice program.
- All MSA Gen6 and Gen7 storage array models are now fully certified for use with HPE Morpheus VM Essentials Software.
- MSA Gen6 HDD and SSD media options supporting an increase in MSA 2060 raw capacity of up to a maximum of 7.37 PB.
- HPE Smart Choice MSA Gen6 storage array bundles with up to 240 TB of raw storage capacity included, supporting 16 Gb Fibre Channel, 10 GbE iSCSI, and 12 Gb SAS host connectivity.
Features
The HPE MSA 2060 Storage delivers virtualized snapshot technology, making data protection and instant recovery a snap.
Accelerate Applications Affordably
Encrypted SSDs and HDDs with local key management can be deployed to deliver a secure, encrypted hybrid flash array.
The HPE MSA 2060 Storage solution supports a mixture of 3.5-inch LFF and 2.5-inch SFF expansion enclosures for a maximum of nine enclosures (10 total including the array).
HPE MSA’s "Set It and Forget It" Data Services Do Not Require a Dedicated Storage Administrator
HPE MSA’s automated tiering engine dynamically responds to workload changes so you don’t have to, ensuring the hottest data will be moved to the fastest media automatically and in real time.
Flexible, Modular Architecture That Facilitates Growth into the Future
Start small and scale as needed with any combination of SSDs, Enterprise SAS HDDs, or Midline SAS HDDs.
The HPE MSA 2060 Storage allows users to define and deploy hybrid or flash storage configurations from day one and grow as their needs change.
Leverage Data Protection Features to Keep Your Business Running in the Event of a Disaster
Remote replication via Fibre Channel (FC) or iSCSI facilitates an affordable disaster recovery solution.
The HPE MSA 2060 Storage is easy to install, easy to use, and easy to maintain, even for an IT generalist. Administrators will find the MSA 2060’s new Storage Management Utility intuitive and easy to navigate.
The HPE MSA 2060 Storage is capable of delivering up to 395,000 IOPS for affordable application acceleration for small to medium-sized businesses. [1]
Media
HPE MSA Storage as a local repository for HPE GreenLake for Backup and Recovery
Learn how HPE GreenLake for Backup and Recovery and HPE MSA Storage work together to provide the perfect solution for protecting your most important data.
Compatible products
- HPE 3 Year Tech Care Essential MSA 2060 Storage Service
- HPE FlexNetwork X240 40G QSFP+ to 4x10G SFP+ 3m Direct Attach Copper Splitter Cable
- HPE 4 Year Tech Care Basic MSA 2060 Storage Service
- HPE LC to LC Multi-mode OM3 2-Fiber 1.0m 1-Pack Fiber Optic Cable
- HPE Aruba Networking 10G SFP+ to SFP+ 7m Direct Attach Copper Cable
- HPE 2.0m External Mini SAS High Density to Mini SAS Cable
- HPE 1U Autoloader Rack Kit
- HPE MSA 960GB SAS 12G Read Intensive SFF (2.5in) M2 3yr Wty SSD
- HPE MSA 2060 SFF DISK ENCLOSURE
- HPE X240 QSFP+ 4x10G SFP+ 5m DAC Cable
- HPE MSA 10.8TB SAS 12G Enterprise 10K SFF (2.5in) M2 3yr Wty 6-pack HDD Bundle
- HPE LC to LC Multi-mode OM3 2-Fiber 5.0m 1-Pack Fiber Optic Cable
- HPE 5 Year Tech Care Essential wCDMR MSA 2060 Storage Service
- HPE LC to LC Multi-mode OM3 2-Fiber 30.0m 1-Pack Fiber Optic Cable
- HPE MSA 48TB SAS 12G Midline 7.2K LFF (3.5in) M2 1yr Wty 6-pack HDD Bundle
- HPE MSA 1.2TB SAS 12G Enterprise 10K SFF (2.5in) M2 3yr Wty HDD
- HPE Bezel Lock Kit
- HPE C13 – C14 WW 250V 10Amp Flint Gray 2.0m Jumper Cord
- HPE 5 Year Tech Care Essential MSA 2060 Storage Service
- HPE 4 Year Tech Care Basic wDMR MSA 2060 Storage Service
- HPE MSA 1060 10GBASE-T ISCSI SFF STORAGE
- HPE MSA 2060 SAS 12G 2U 12-disk LFF Drive Enclosure
- HPE External 4.0m (13ft) Mini-SAS HD 4x to Mini-SAS HD 4x Cable
- HPE Cablu Server HP Premier Flex LC/LC Multi-mode OM4 2 fiber 1m Cable
- HPE BladeSystem c-Class 10GbE SFP+ to SFP+ 5m Direct Attach Copper Cable
- HPE C13 – C14 WW 250V 10Amp 2.0m Jumper Cord
- HPE MSA 600GB SAS 12G Enterprise 10K SFF (2.5in) M2 3yr Wty HDD
- HPE LC to LC Multi-mode OM3 2-Fiber 15.0m 1-Pack Fiber Optic Cable
- HPE 3 Year Tech Care Essential wDMR MSA 2060 Storage Service
- HP Cablu DAC X240 SFP+ 7m (JC784C)
- HPE MSA 1.92TB SAS 12G Read Intensive LFF (3.5in) M2 3yr Wty SSD
- HPE MSA 14.4TB SAS 12G Enterprise 10K SFF (2.5in) M2 3yr Wty 6-pack HDD Bundle
- HPE 3 Year Tech Care Basic wDMR MSA 2060 Storage Service
- HPE X240 QSFP28 4xSFP28 3m DAC Cable
- HPE Ext 1.0m MiniSAS HD to MiniSAS Cbl
- HPE 4 Year Tech Care Critical MSA 2060 Storage Service
- HPE 4 Year Tech Care Essential wCDMR MSA 2060 Storage Service
- HPE Cablu storage Server Premier Flex LC/LC Multi-mode OM4 2 Fiber 5mCable
- HPE Aruba Networking 10G SFP+ to SFP+ 1m Direct Attach Copper Cable
- HPE 4 Year Tech Care Essential wDMR MSA 2060 Storage Service
- HPE MiniSAS HD to MiniSAS HD FO 2M Cbl
- HPE MSA 2.4TB SAS 12G Enterprise 10K SFF (2.5in) M2 3yr Wty HDD
- HPE 5 Year Tech Care Critical MSA 2060 Storage Service
- HPE 100Gb QSFP28 to 4x25Gb SFP28 3m Direct Attach Copper Cable
- HPE MSA Advanced Data Services LTU
- HPE MSA 1.8TB SAS 12G Enterprise 10K SFF (2.5in) M2 3yr Wty HDD
- HPE MSA Family Startup SVC
- HPE MSA 3.84TB SAS 12G Read Intensive SFF (2.5in) M2 3yr Wty SSD
- HPE 4 Year Tech Care Essential MSA 2060 Storage Service
- HPE LC to LC Multi-mode OM3 2-Fiber 0.5m 1-Pack Fiber Optic Cable
- HPE Premier Flex LC/LC Multi-mode OM4 2 Fiber 50m Cable
- HPE MSA 1.92TB SAS 12G Read Intensive SFF (2.5in) M2 3yr Wty SSD
- HPE LC to LC Multi-mode OM3 2-Fiber 50.0m 1-Pack Fiber Optic Cable
- HPE Networking X240 10G SFP+ SFP+ 3m DAC Cable
- HPE 4 Year Tech Care Basic wCDMR MSA 2060 Storage Service
- HPE External 2.0m (6ft) Mini-SAS HD 4x to Mini-SAS HD 4x Cable
- HPE 3 Year Tech Care Essential wCDMR MSA 2060 Storage Service
- HPE C13 – KSC- 8305 KR 250V 10Amp 1.83m Power Cord
- HPE Install MSA Array + Enclosure SVC
- HPE Premier Flex LC/LC Multi-mode OM4 2 Fiber 2m Cable
- HPE 3 Year Tech Care Basic wCDMR MSA 2060 Storage Service
- HPE MSA 72TB SAS 12G Midline 7.2K LFF (3.5in) M2 1yr Wty 6-pack HDD Bundle
- HPE 4 Year Tech Care Critical with DMR MSA 2060 Storage Service
- HPE X240 QSFP+ 4x10G SFP+ 1m DAC Cable
- HPE Premier Flex LC/LC OM4 2f 30m Cbl
- HPE Mini SAS HD to MiniSAS HD FO 4M Cbl
- HPE 5 Year Tech Care Basic wDMR MSA 2060 Storage Service
- HPE MSA Advanced Data Services E-LTU
- HPE External 1.0m (3ft) Mini-SAS HD 4x to Mini-SAS HD 4x Cable
- HPE MSA 10Gb Short Range iSCSI SFP+ 4-pack Transceiver
- HPE Aruba Networking 10G SFP+ to SFP+ 3m Direct Attach Copper Cable
- HPE 3 Year Tech Care Basic MSA 2060 Storage Service
- ARUBA 25G SFP28 TO SFP28 3M DIRECT
- HPE 3 Year Tech Care Critical with CDMR MSA 2060 Storage Service
- HPE C13 – CEE-VII EU 250V 10Amp 1.83m Power Cord
- HPE 5 Year Tech Care Critical with CDMR MSA 2060 Storage Service
- HPE MiniSAS HD to MiniSAS HD FO 1M Cbl
- HPE MSA 8TB SAS 12G Midline 7.2K LFF (3.5in) M2 1yr Wty HDD
- HPE MSA 16Gb Short Wave Fibre Channel SFP+ 4-pack Transceiver
- HP Cablu DAC X240 SFP+ SFP+ 5m (JG081C)
- HPE 5 Year Tech Care Basic wCDMR MSA 2060 Storage Service
- HPE 3 Year Tech Care Critical with DMR MSA 2060 Storage Service
- HPE MSA 7.2TB SAS 12G Enterprise 10K SFF (2.5in) M2 3yr Wty 6-pack HDD Bundle
- HPE MSA 6TB SAS 12G Midline 7.2K LFF (3.5in) M2 1yr Wty HDD
- HPE 1.83m 10A C13-UL Dom Pwr Cord
- HPE 5 Year Tech Care Critical with DMR MSA 2060 Storage Service
- HPE Networking X240 10G SFP+ SFP+ 0.65m DAC Cable
- HPE Networking X240 10G SFP+ SFP+ 1.2m DAC Cable
- HPE 5 Year Tech Care Essential wDMR MSA 2060 Storage Service
- HPE 5 Year Tech Care Basic MSA 2060 Storage Service
- HPE LC to LC Multi-mode OM3 2-Fiber 2.0m 1-Pack Fiber Optic Cable
- HPE 4 Year Tech Care Critical with CDMR MSA 2060 Storage Service
- HPE MSA 96TB SAS 12G Midline 7.2K LFF (3.5in) M2 1yr Wty 6-pack HDD Bundle
- HPE BladeSystem c-Class 10GbE SFP+ to SFP+ 3m Direct Attach Copper Cable
Documents
- HPE MSA Gen7 Virtual Storage Technical Reference Guide
- Migrating to HPE MSA Gen7 Storage
- HPE MSA Gen6 Virtual Storage Technical Reference Guide
- HPE MSA Storage configuration for Bosch Video Management System
- Deployment considerations for HPE MSA Gen6 with VMware vSphere 7
- HPE MSA Gen5 virtual storage: Technical Reference Guide
- HPE MSA 2060 Storage for Milestone XProtect
- Deployment considerations for HPE MSA Gen6 Storage with VMware vSphere 8
- Finding balance in an entry-level storage system
- HPE NonStop Proactive 24 Service
- Packaging giant builds platform for sustainable growth – EPL Limited
- Packaging giant builds platform for sustainable growth – EPL Limited
- HPE MSA Gen6 Storage
- HPE Cluster Extension Solution Implementation Service
- HPE MSA 2060 Storage Array QuickSpecs
- Migrating to HPE MSA Gen6 Storage – Strategy and technical reference guide
- Video surveillance verification with HPE MSA 2060 Storage array and Milestone XProtect
[1] Based on internal testing. See MSA QuickSpecs for details (www.hpe.com/storage/msa).
